DOSERPUMPAR
"F" & "FMS" DIGITAL
Stroke speed adjustment with fixed stroke length for low cost
application.
Wide control possibilites without external pacer such as pulse
division and multiplication, 4-20 mA, mV, V input, timer and
double timer.
Features pH, ORP potential (redox), conductivity and cooling tower
built-in controllers. "F" MODELS & CONTROL PANELS
"FCO"
Constant pump with stroke speed adjustment
"FCL"
Constant pump with level control, stroke speed adjustment
"FPV"
Constant-proportional pump driven by external digital signal, with
pulse divider mode
"FPVM"
Constant-proportional pump driven by external digital signal with
pulse division and multiplication
"FIC"
Constant-proportional pump driven by current signal (0/4 mA = 0
pulses, 20 mA = max pulses) and level control
"FTE"
(0"-60") timered pump with external digital start signal and level
control
"FPDR"
Metering pump with adjustable operation and stand-by times
"FIS"
Constant-proportional pump driven by external digital signal, with
level control: one internal pulse corresponds to one pump stroke
| |
FCO |
FCL |
FIC |
FIS |
FPV |
FPVM |
FTE |
FPDR |
| Input signals |
None |
mA current |
Digital pulses |
Start pulses |
None |
| Internal
controller |
Stroke speed |
None |
Pulse divider |
Pulse divider &
multiplier |
Internal timer |
Dual timer |
| Alarm output |
Level
on demand |
"FMS" DIGITAL MODELS & CONTROL PANELS
"FMS EN"
Pump with weekly timer, microprocessor, digital controls, LCD
display, level control and electrovalve control output
"FMS PH"
Proportional pump driven by internal built-in pH meter (0-14 pH)
and level control
"FMS RH"
Proportional pump driven by internal built-in Redox (ORP) meter
(0-1000 mV) and level control
"FMS CD"
Proportional pump driven by internal built-in conductivity meter
(0-20 mS), supplied with conductivity probe (mod. ECDCC) with
automatic temperature compensation
"FMS CDT"
Pump driven by internal built-in conductivity meter for cooling
tower applications, with one set point and hysteresis control for
water bleed, supplied with Conductivity probe (mod. ECDCC) with
automatic temperature compensation
| |
FMS EN |
FMS PH |
FMS RH |
FMS CD |
FMS CDT |
| Input signals |
-- |
pH probe |
Redox probe |
Conductivity
probe |
Conductivity
probe |
| Internal
controller |
Weekly timer |
pH meter
proportional |
Redox meter
proportional |
Proportional
conductivity meter |
Hysteresis
conductivity meter |
| Alarm output |
Level on demand |
| |
Pump head |
Diaphragm |
Ball checks |
Valve
cartridge |
Hose
connection |
Foot filter |
Hoses |
O-rings |
| Standard |
PP |
PTFE |
Glass |
Polypropyl. |
Polypropyl. |
Polypropyl. |
PE |
Viton |
| On demand |
PVDF |
-- |
PTFE
Ceramic
SS |
PVDF |
PVDF |
PVDF |
PVDF
PVC |
EPDM
NBR |
| Flow |
Max capacity
(l/h) |
Max pressure
(bar) |
Capacity
(l/h) |
Pressure
(bar) |
Stroke (ml) |
Strokes (/min) |
Hoses (mm) |
Watt (W) |
Shipping
weight (kg) |
| 12 1,5 |
1,5 |
12 |
2,5 |
6 |
0,17 |
150 |
4x6
PVDF 6x8 |
16 |
2,2 |
| 10 2,2 |
2,2 |
10 |
3 |
5 |
0,25 |
| 07 03 |
3 |
7 |
4 |
3,5 |
0,34 |
| 07 05 |
5 |
7 |
0,56 |
| 05 05 |
5 |
2,5 |
| 06 06 |
6 |
6 |
8 |
3 |
0,67 |
| 05 07 |
7 |
5 |
2,5 |
0,78 |
| 01 07 |
1 |
9 |
0,5 |
| 01 09 |
9 |
9,5 |
1 |
| 10 05 |
5 |
10 |
6,5 |
5 |
0,56 |
19 |
| 05 10 |
10 |
5 |
12 |
2,5 |
1,10 |
| 05 0,2 |
0,2 |
0,9 |
0,25 |
15 |
16 |
Power supply: 117 - 220 - 24
VDC
Other power supplies are available on demand
The "F" series are available with PVDF and PP pump heads. All pump
heads are also available with self-venting feature.
"FAC EX"
PNEUMATIC METERING PUMP
The vertically mounted series "FAC-EX" diaphragm (magnetic)
metering pumps afford the ideal solution for problems encountered
when metering small quantities in an "explosion-proof" environment.
All-plastic housing (glass-filled polypropylene) is resistant to
corrosive chemical agents. Front panel is made of PP-glass.
Membrane is actioned by a pneumatic cylinder driven by a pneumatic
valve. Valve's frequency may be frequency-regulated. All "FAC-EX"
metering pumps have a diaphragm made of PTFE. This material is
very resistant to mechanical movements and guarantees great
chemical compatibility.
Air requirement: 280 l/h
Air pressure: 6-8 bar
Injections per minute: 6-88
Working temperature: 5-45 C
Valves with double glass ball (Pirex)
Idraulic parts made of PP or PVDF (on demand)
Glass-filled PP
PTFE diaphragm
Meets IP65
Width: 91,5 mm
Height: 168 mm
Depth: 160 mm
Net weight: 2 kg "FPER" & "FPER2" PERISTALTIC METERING PUMPS "FPER"
Peristaltic metering pump with electronic timer, designed and
built to solve small metering problems. Flow may be set using the
knob on pump's control panel. It is also possible to set the
dosing time. Timer is activated when pump is turned on. New cycle
is activated when pump is switched off and turned on again. "FPER2"
Peristaltic metering pump with double electronic timer for "work-pause"
cycles. Timer can be auto-activated using an external signal such
as an electrovalve. Flow may be set using pump's knobs on control
panel. It is also possible to set the dosing time.
| Technical
features |
"FPER" |
"FPER2" |
| Power supply |
220
VAC |
| Power
consumption |
5W |
| Protection
standard |
IP65 |
| Engine RPM |
32 |
| Flow |
2,2
l/h |
| Flow-RPM |
1,15
cc |
| Pressure |
1
bar |
| Hose fitting |
4x6,
5x7 |
| Hose
construction material |
thermoplastic |
"G" & "GMS" DIGITAL MODELS Stroke
speed adjustment with fixed stroke length for low cost application.
Wide control possibilities without external pacer such as pulse
division and multiplication, 4-20 mA, mV, V input and timer with
start signal input. Features built-in pH and ORP
potential (redox) instruments. "G" MODELS & CONTROL
PANELS "G CO"
Constant pump with stroke speed adjustment "G CL"
Constant pump with level control, stroke speed adjustment
"G IS"
Constant-proportional pump driven by external digital signal, with
level control: one external pulse corresponds to one pump stroke
"G PVM"
Constant-proportional pump driven by external digital signal, with
pulse division and multiplication "G PV"
Constant-proportional pump driven by external digital signal, with
pulse divider mode "G IC"
Constant-proportional pump driven by current signal (0/4 mA = 0
pulses; 20 mA = max pulses) and level control "G TE"
(0"-60") timered pump with external digital start signal and level
control
| |
GCO |
GCL |
GIS |
GPV |
GPVM |
GIC |
GTE |
| Input signals |
None |
Digital pulses |
mA current |
Start pulses |
| Internal
controller |
Stroke speed |
None |
Pulse divider |
Pulse divider &
multiplier |
None |
Internal timer |
| Alarm output |
Level
on demand |
"GMS" DIGITAL MODELS & CONTROL PANELS
"GMS MAN"
Constant pump with level control and stroke frequency digital
control "GMS EXT"
Multifunction-proportional pump with analogic and digital signal
input, level control "GMS PH"
Proportional pump driven by internal built-in pH meter (0-14 pH)
and level control "GMS RH"
Proportional pump driven by internal built-in Redox (ORP) meter
(0-100 mV) and level control
| |
GMS MAN |
GMS EXT |
GMS PH |
GMS RH |
| Input signals |
None |
Digital pulses
mA current
V voltage
mV voltage |
pH probe |
Redox probe |
| Internal
controller |
Stroke speed |
Pulse divider
and multiplier
Analog signal proportional range definition |
pH meter
proportional |
Redox meter
proportional |
| Alarm output |
Level on demand |
The "G" series are available with acrylic, PVDF, stainless steel
and PP pump heads. All pump heads are available with self-venting
feature except stainless steel pump heads.
| |
Pump head |
Diaphragm |
Ball checks |
Valve
cartridge |
Hose
connection |
Foot filter |
Hoses |
O-rings |
| Standard |
Polypropyl. |
PTFE |
Glass |
Polypropyl. |
PE |
Viton |
| On demand |
PVDF
Acrylic
S.S. |
-- |
PTFE
Ceramic
S.S. |
PVDF
SS |
PVDF |
PVDF
PVC |
EPDM
NBR |
| Flow |
Max capacity
(l/h) |
Max pressure
(bar) |
Capacity
(l/h) |
Pressure
(bar) |
Stroke (ml) |
Strokes (/min) |
Hoses (mm) |
Watt (W) |
Shipping
weight (kg) |
| 20 01 |
1 |
20 |
1,3 |
10 |
0,14 |
G150
GMS120 |
4x8 |
22 |
4,1 |
| 18 02 |
2 |
18 |
2,5 |
9 |
0,23 |
| 15 03 |
3 |
15 |
4 |
8 |
0,33 |
4x6
PVDF 6x8 |
| 20 05 |
5 |
20 |
6 |
10 |
0,55 |
150 |
4x8 |
27 |
5,7 |
| 10 05 |
10 |
5,5 |
5 |
0,56 |
G150
GMS120 |
4x6
PVDF 6x8 |
22 |
4,1 |
| 12 07 |
7 |
12 |
9 |
6 |
0,98 |
150 |
27 |
5,7 |
| 07 07 |
7 |
7,5 |
3,5 |
0,78 |
G150
GMS120 |
22 |
4,1 |
| 10 10 |
10 |
10 |
12 |
5 |
1,4 |
150 |
27 |
5,7 |
| 05 10 |
5 |
11,5 |
2,5 |
1,1 |
G150
GMS120 |
22 |
4,1 |
| 05 15 |
15 |
18 |
2,1 |
150 |
6x8 |
27 |
5,7 |
| 01 15 |
1 |
17 |
0,5 |
1,7 |
G150
GMS120 |
4x6
PVDF 6x8 |
22 |
4,1 |
| 04 20 |
20 |
4 |
22 |
2 |
2,8 |
150 |
6x8 |
27 |
5,7 |
| 03 30 |
30 |
3 |
33 |
1,5 |
4,2 |
8x12
PVDF 8x10 |
| 01 50 |
50 |
1 |
54 |
0,5 |
7 |
| 00 100 |
100 |
0 |
-- |
-- |
14 |
"GAC" - PNEUMATIC MEMBRANE METERING PUMP
Series "GAC" membrane metering pumps are driven by an electronic
circuit consisting of a professional PCB and electronic components
of proven quality for top reliability. An all-plastic container
ensures that both the electronics and mechanical parts are
protected against chemical attack. The hydraulic seal is provided
by a PTFE diaphragm and five types of elastomer selected to suit
the metered product. Easy-to-operate control functions are
represented by graphic symbols on a tough polycarbonate panel.
Series "GAC" pumps are available in six basic models:
"GAC-CO"
Constant stroke deilvery with adjustable flow rate "GAC-CL"
As GAC-CO plus level control "GAC-PV"
Proportional flow pump driven by a digital signal with divider
from 1 to 1000 (in conjunction with pulse counter) "GAC-IC"
Proportional flow pump driven by an external current signal (0-20
mA and 4-20 mA) "GAC-IS"
Proportional flow pump piloted by digital signal, each pulse
producing one injection "GAC-TE"
Pump with 10"-60" timer control and digital start signal
Electrical consumption: 5W
Number of injections: 0-120
Input signal:
Current input: 0-20 mA & 4-20 mA
Digital input (free contact)
Level probe input
Working temperature: 5-45 C
Double ball suction and delivering valve
Box and liquid end in PP - PTFE diaphragm
Meets IP65
Power: 230 VAC +/-10%
Inhaled air consumption: 1950 l/h
Air pressure: 6-9 bar "GAC EX" PNEUMATIC MEMBRANE
METERING PUMP Vertically mounted series "GAC EX"
diaphragm metering pumps offer the ideal solution for problems
encountered when metering medium quantities in an "explosion-proof"
environment. An all-plastic housing (glass-filled polypropylene)
is resistant to corrosive chemical agents. Front panels are made
of PP-glass. Diaphragm is actioned by a pneumatic cylinder driven
by a pneumatic valve. Valve's frequency may be regulated using a
knob. This way, it is possible to reach the pump's desired flow
value. All "GAC EX" metering pumps have a diaphragm made of PTFE.
This material is very resistant to mechanical movements and
guarantees great chemical compatibility. Air
requirement: 1600 l/h
Air pressure: 6-8 bar
Injections per minute: 6-110
Working temperature: 5-45 C
Valves with double glass ball (Pirex)
Idraulic parts made of PP or PVDF (on demand)
Glass-filled PP
PTFE diaphragm
Meets IP65
Width: 225 mm
Height: 275 mm
Depth: 165 mm © 2012 BML Hydroteknik AB |
